FBK-13DC Sealing and Sewing Automatic Big Bag Packaging Machine

SKU

体积

尺寸

装箱数

重量

价格￥

135,000.00

($) US dollar price changes with exchange rate

立即购买

Detail

FBK series

sealing and sewing automatic packaging machine

FBK-13DC

Product Description: FBK series automatic sealing and sewing packaging machine is suitable for heavy-duty big bag with a packaging weight of 25 ~ 50kg, suitable for packaging with single (multi) layer Kraft paper bag, paper plastic (PE) combination bag or paper plastic woven combination bag, etc, this series of models can automatically complete the processes such as dust removal (optional), bag opening, trimming, stitching, cutting thread chain, paper tape, paper cutting tape, heat sealing, pressing and counting according to the procedure.

This series of models adopt advanced technology of integration of light, machine and electricity, realizing automation and high efficiency.

This series has 9 standard models, providing users with a wide range of choices.

The sealing, sewing, wrapping paper tape and hot pressing bags have excellent sealing performance, which can prevent dust, moth and pollution, so that the packages are properly protected.

Technical parameters:

FBK-13C

FBK-13DC

FBK-14C

FBK-13DC

FBK-23C

FBK-23DC

FBK-24C

FBK-24DC

FBK-332C

power supply voltage (V/Hz)

AC 380/50

Total power

4

4.5

5.5

6

4

4.5

5.5

6

6.5

Transmission power (KW)

0.37

0.75

0.37

0.75

Driving power of sewing machine (KW)

0.37

Heating power (KW)

0.5 × 6

0.5 × 8

0.5 × 6

0.5 × 8

0.5 × 10

Dust removal power (KW)

-

0.6

-

0.6

-

0.6

-

0.6

-

Sealing speed (m/min)

0-11

Height of sealing center to ground (mm)

8.5 (customizable customiZe 5~11)

Minimum height from material to pocket (mm)

170

Temperature control range (℃)

0-400

Air source pressure (Mpa)

0.6

Paper tape

O

△

Dust Collector

×

√

×

√

×

√

×

√

×

Application

Multiwall paper bag, paper-plastic compound pocket, two-in-one, three-in-one bag, etc.

Multiwall paper bag, paper-plastic compound pocket, two-in-one, three-in-one bag, lined with aluminum plastic or PE membrane bag, etc.

Overall dimension (L × W × H)(mm)

2600 × 950 × 1800

2800 × 950 × 1800

2700 × 950 × 1800

2800 × 950 × 1800

3030 × 950 × 1800

Net Weight (kg)

450

500

550

400

450

500

600

? The minimum height from the material to the pocket is 170mm ○ = hot melt coated paper tape? Sealing temperature: 0-400℃ △ = crease paper belt? ? Compressed air consumption: 200Nl/min, pressure 5kg/cm × = not selected? Sealing height: 900-1450mm? Dust Collector consumption function: 0.6KW? Removable exhaust mechanism:? Model "C" indicates the wrapping tape mechanism "D" indicates that the dust removal mechanism is configured.
