OMRON type Temperature Controller E5C2 R20K 0-400 degrees one year guarrtee
SKU
体积
尺寸
装箱数
重量
价格￥
1.00
($) US dollar price changes with exchange rate
Detail
E5 series temperature controller E5C2 small volume, light weight, beautiful outline, good reliability
| Applicable Scope |
| Our E5 series meter totally adopts imported elements with small volume, light weight, beautiful outline, good reliability, strong shock resistance and anti-jamming. It can be widely used for temperature measure and autocontrol in different industries like plastic machinery,rubber machinery,packing machinery,dress, food and printing &dyeing etc. |
| Main Technical Data |
|
Tmp. Range
|
0-99.9°C, 0-199°C, 0-299°C, 0-399°C, 0-999°C
|
|
|
Input Specification
|
(K,J),PT100Ω
|
|
|
Setting precision
|
Less than ±1% full scale or range display
|
Less than 0.5% full scale or range displ
|
|
Indicating precision
|
Less than ±2°C
|
|
|
Control Action
|
ON/OFF type , proportion type (PD)
|
|
|
Output Mode
|
Relay connection point 5A 250VAC, voltage of non ecting point 12VDC for SSR use
|
|
|
Rated Voltage
|
AC:110V/220V/380V±10%,50/60Hz
|
|
|
Proportion Cycle
|
Relay:15secs, Non connection point :2secs
|
|
|
power Consumption
|
3W
|
|
|
Ambient Temperature
|
-10°C~+55°C
|
|
