Main features:
Jhk collection and processing display module in one
Small size, light weight, easy to carry
Products are easy to use, low power consumption
Blood oxygen saturation values display
Pulse rate values, bar graph display
Pulse waveform display
Battery power indicator
How can change the displayed 4 Direction change
Automatic power off function : Under the status of the measure interface , Measured finger after undocking 5s Automatic shutdown
Product performance:
Display modes: 1.1 Inches Color OLED Screen display
Monitor resolution: 96*64
Precision : 70% ~ 100% : ±2% Is less than 70% Not defined
Pulse rate measuring range: 30bpm ~ 250bpm (Resolution of 1bpm )
Accuracy: ±2bpm Or ±2% Max value
Error under low perfusion: pulse filled in for 0.4% When blood oxygen meter displays blood oxygen saturation and pulse rate values correctly, blood oxygen saturation errors ±4% And pulse rate errors ±2bpm Or ±2% Max value.
Ambient light interference resistance: natural light in the room and blood oxygen measurement under the existing lighting and darkroom conditions compared to the measured values of deviation is less than ±1%
Power consumption: less than 30 mA
Working voltage: DC 3.0V
Battery: 2 The seventh 1.5V Alkaline batteries
Battery working time: minimum sustainable work 20 Hours theoretical value is 32
Security type: internal power supply ,BF Application part
Net weight: 50 g each
Packing information: 240/box
Size: 490MM*265MM*490MM
